Airfinity Packaged Rooftop

Cooling capacity: 20 - 134 kW

Heating capacity: 20 - 132 kW

pictospictospictospictospictospictospictospictos
  • Optimum comfort and high Indoor Air Quality
  • Energy savings: Free cooling and heat recovery solutions for maximum energy savings
  • High performance: High efficiency hermetic scroll type compressors in tandem for high seasonal efficiency,
  • Integrated and pre-configured controls that substantially reduce installation and commissioning time
  • Best-in-class EC plug type ventilation fans and tandem scroll compressors, delivering high efficiency at both full load and part load

All-in-one system at the lowest operating costs

Airfinity™ rooftop air-to-air units combine heating, cooling, and ventilation all in one package, for simplified installation and operation. They are suitable for a wide range of applications, particularly where low initial cost and easy installation are important such as supermarkets, shopping malls, cinemas and restaurants.

With a strong legacy of proven reliability, Airfinity rooftops can deliver high seasonal efficiency standards capable of meeting even the most stringent European regulations. By reducing energy and maintenance costs, you can lower your cost of ownership.

Integrated plug & play solution

Our packaged system features integrated controls engineered to create the best possible comfort environment for your investment.

Equipped with EC plug fans and high efficiency tandem scroll compressors, Airfinity™ units are designed to adapt the fan rotation speed according to building load and ventilation requirements. Not only does this improve comfort for occupants by preventing cold drafts, it can also reduce energy consumption by 60% over the lifetime of the unit.

Highly configurable and adaptable

Every Airfinity unit can be customized to meet your exact building type and application specifications, with a wide range of options and accessories including energy saving solutions and a large selection of filtration options to increase indoor air quality.

Airfinity™ rooftop units connect directly to local ductwork, with or without a roof curb. Several airflow configurations are available, ensuring quick and hassle-free installation.

For colder climates, complementary heating sources are available such as gas burners or hot water coils. The smart Trane CH536 unit controller automatically manages multiple heat sources depending on climate conditions and the building load.

Simplified control solutions

Airfinity™ units are equipped with sensors that enable them to regulate the room temperature as soon as they are turned on. For tighter temperature and IAQ control, several options are available.

With the unique Trane Tracer™ Concierge building management system, you can manage multiple rooftop units in a cost-effective and easy way.

RANGE DESCRIPTION
  • Airfinity™ is available in 20 different sizes with a wide selection of energy saving and technical options and accessories.

  • IC: Cooling-only and gas-fired units — IH: Reversible and dual fuel units

Technical Specifications

Product name Cooling capacity Heating capacity Eurovent certification ErP Certification
Airfinity Packaged Rooftop 20-134 kW 20-132 kW
Compressor Refrigerants Energy saving Operating mode Data protocols Unit type
N/A R454B | R410A Heat recovery
Free cooling
Adaptive frequency
Cooling only
Cooling only and electric heater
Heat pump
Lonmark
Bacnet
Modbus
Air-to-air
